| 型号 | 输入电压范围 (VDC) | 输出电压 (VDC) | 功率 (W) | 隔离耐压 (VDC) | 封装形式 | 产品尺寸(mm) | ||
|---|---|---|---|---|---|---|---|---|
| URA2403YMD-6WR3 | 24 | ±3.3 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA2405YMD-6WR3 | 24 | ±5 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA2409YMD-6WR3 | 24 | ±9 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA2412YMD-6WR3 | 24 | ±12 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA2415YMD-6WR3 | 24 | ±15 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA2424YMD-6WR3 | 24 | ±24 | 6W | 1500VDC | DIP | |||
| URA11024YMD-6WR3 | 110 | ±24 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA11015YMD-6WR3 | 110 | ±15 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA11012YMD-6WR3 | 110 | ±12 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA11009YMD-6WR3 | 110 | ±9 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA11005YMD-6WR3 | 110 | ±5 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA11003YMD-6WR3 | 110 | ±3.3 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4824YMD-6WR3 | 48 | ±24 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4815YMD-6WR3 | 48 | ±15 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4812YMD-6WR3 | 48 | ±12 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4809YMD-6WR3 | 48 | ±9 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4805YMD-6WR3 | 48 | ±5 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 | ||
| URA4803YMD-6WR3 | 48 | ±3.3 | 6W | 1500VDC | DIP | 25.4*25.4*11.00 |
