| 型号 | 输入电压范围 (VDC) | 输出电压 (VDC) | 功率 (W) | 隔离耐压 (VDC) | 封装形式 | 产品尺寸(mm) | ||
|---|---|---|---|---|---|---|---|---|
| E2403S-1W | 24 | 3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E2405S-1W | 24 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E2409S-1W | 24 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E2412S-1W | 24 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E2424S-1W | 24 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E2415S-1W | 24 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1503S-1W | 15 | ±3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1505S-1W | 15 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1509S-1W | 15 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1512S-1W | 15 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1515S-1W | 15 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1524S-1W | 15 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1203S-1W | 12 | ±3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1205S-1W | 12 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1209S-1W | 12 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1212S-1W | 12 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1215S-1W | 12 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E1224S-1W | 12 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0903S-1W | 9 | ±3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0905S-1W | 9 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0909S-1W | 9 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0912S-1W | 9 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0915S-1W | 9 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0924S-1W | 9 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0503S-1W | 5 | ±3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0505S-1W | 5 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0509S-1W | 5 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0512S-1W | 5 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0515S-1W | 5 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0524S-1W | 5 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0303S-1W | 3.3 | ±3.3 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0305S-1W | 3.3 | ±5 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0309S-1W | 3.3 | ±9 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0312S-1W | 3.3 | ±12 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0315S-1W | 3.3 | ±15 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 | ||
| E0324S-1W | 3.3 | ±24 | 1W | 3000VDC | SIP7 | 19.65*6.00*9.50 |
